Lucas Mill- 830 - 8" Cut Sawmill

Complete 8" Lucas Model 830 Portable Sawmill Package
Click images to view larger
Description:

The Model 8-30 is currently the most popular choice in the Lucas Mill range. This machine hosts a powerful Kohler EFI V-twin electric start motor. The Side Shift Winder and Standard Track Extensions are included as standard with this model. A full range of optional accessories are available for this model.

Options:-

2 metre extension beam extension kit

6", 8" or 10" slabber attachment

Dedicated slabber (complete head unit) 16hp Briggs & Stratton man start

Bevel attachment for weatherboarding

Log Lift for lifting timber

Metal Detector Kit approx 14" depth

Technical Specifications:



Engine Electric start, EFI V-twin petrol 30hp
Transmission

5" centrifugal clutch, 3 SPA 1000 belts, 30mm shaft

1 piece hub/shaft assembly

Sawblades 5 tooth TCT 3.2mm plate, 5.7mm kerf
Cut Length Up to 6.1m in standard form
Cut Sizes

Up to 215mm x 215mm (8½” x 8½”)
Double cut up to 215mm x 430mm (8½” x 17”)

Side Winder Standard
Weights
Carriage 168kg
Tracks 61kg
End-frames 81kg
Shipping Weight 420kg
Shipping sizes

Box: 1.03m x 0.75m x 2.85m

Tracks: 0.3m x 0.2m x 6.1m

Slabber Optional



Key Features:

Video:
Brochure Download:
