Uniforest- Scorpion Premium

Click images to view larger
Description:

SCORPION PREMIUM are the new high-quality and technologically-advanced generation of tongs for timber manipulation.

SCORPION PREMIUM timber tongs are intended for timber manipulation. Due to their characteristics they are suitable for use in all weather conditions. The basic guideline in the development of the new tongs was easy operation and a long service life. We've achieved this with simple solutions and high-quality components hidden under a dynamic yet robust framework with design lines typical of Uniforest. The adjustable sliding system on the telescopic arm helps eliminate the clearance between the sliding plastic and the metal. In addition, the sliding plastic is made of a special material that does not require lubrication.

  • 20% greater load capacity
  • Unique design
  • Compact/Robust construction
  • Made of high quality materials
  • Best anti-corrosion protection
  • Possible lubrication of moving parts
  • Low maintenance costs
Technical Specifications:


Premium 1 Premium 2 Premium 3 Premium 4
Max. opening (mm) 1800 1800 1800 1800
Min. diameter (mm) 70 70 70 70
Length of butt plate (mm) 985 985 985 985
Whole length of machine (mm) 1865 1865 2025 1865
Whole height of machine (mm) 1420 1420 1420 1420
Gripping power of cylinder (kN)
95 95 95 95
Telescopic arm extension (mm) 600 600 600 600
Swivel range (degrees) 55+55 55+55 55+55 55+55

Butt plate extension

Optional Optional Optional

Optional

Recommended tractor power (KW) 50-80 50-80 50-80 50-80
Recommended tractor power (HP) 36-59 36-59   36-59 36-59
Hydraulic swivel left-right Standard Standard Standard Standard
Telescopic arm hydraulic extension 2300 2300 2300 2300
Hydraulic rotator Optional Standard Standard Standard
Control block Optional Optional Standard  Optional
Weight (kg) 525 540 565 530





Key Features:


THE ROBUST FRAME PROTECTS THE INTERIOR

Hydraulic hoses and cylinders are covered with a robust yet dynamically shaped frame for protection against mechanical damage. This ensures minimal maintenance costs and extends the life of the machine.



THE TELESCOPIC DRAWBAR

can be moved 55° to the left or right.




TECHNOLOGICAL EXCELLENCE FOR A LONGER LIFE

The adjustable sliding system on the telescopic arm helps eliminate the clearance between the sliding plastic and the metal. In addition, the sliding plastic is made of a special material that does not require lubrication.
